The D-Link DES-F1016P-E/B is a professional-grade 16-port unmanaged PoE+ surveillance switch engineered for IP surveillance systems, wireless access points, VoIP deployments, and small to medium-sized business networks. Equipped with 16 Fast Ethernet PoE+ ports, 2 Gigabit uplink ports with 1 Combo (RJ45/SFP), and a generous 150W PoE power budget, this switch delivers both power and data through a single Ethernet cable, simplifying network installations. Featuring 250-meter Long Range PoE mode, intelligent surveillance functions, and Plug-and-Play operation, the DES-F1016P-E/B provides reliable, stable, and cost-effective networking for professional CCTV and enterprise environments.

Key Features

• 16 Fast Ethernet PoE+ Ports: Provides power and network connectivity for IP cameras, wireless access points, and other IEEE 802.3af/at PoE devices.
• 250m Long Range PoE: Extend Mode supports PoE transmission up to 250 meters, ideal for long-distance surveillance installations.
• 2 Gigabit Uplink Ports: High-speed uplink ports with 1 Combo (RJ45/SFP) provide fast backbone connectivity.
• 150W Total PoE Budget: Delivers sufficient power for multiple PoE-enabled devices simultaneously.
• VLAN Isolation Mode: Reduces broadcast traffic and improves network security for surveillance environments.
• QoS Priority Mode: Optimizes video transmission for smooth and uninterrupted surveillance footage.
• PoE Watchdog (Power Recovery): Automatically detects and restarts unresponsive PoE devices to minimize downtime.
• Plug-and-Play Operation: No software configuration required for quick deployment.
• 6KV Lightning Protection: Protects connected equipment from electrical surges.
• Fanless Metal Housing: Durable, silent operation suitable for offices, control rooms, and surveillance applications.

Technical Specifications

• Brand: D-Link
• Model: DES-F1016P-E/B
• Product Type: Unmanaged PoE+ Surveillance Switch
• PoE Ports: 16 × 10/100Mbps Fast Ethernet RJ45 Ports
• Uplink Ports: 2 × Gigabit Ports with 1 Combo (RJ45/SFP)
• PoE Standard: IEEE 802.3af / IEEE 802.3at
• Total PoE Budget: 150W
• Long Range PoE: Up to 250 Meters (Extend Mode)
• Switching Capacity: 7.2Gbps
• Packet Forwarding Rate: 3.868Mpps
• Flow Control: IEEE 802.3x
• Surge Protection: 6KV Lightning Protection
• Power Supply: 100–240V AC, 50/60Hz
• Dimensions: 285 × 180 × 44 mm
• Weight: 2.1kg
• Colour: Black

Professional PoE Surveillance Networking

The D-Link DES-F1016P-E/B is purpose-built for professional IP surveillance systems, allowing installers to power and connect multiple IP cameras through a single Ethernet cable. Its 150W PoE budget supports numerous PoE devices while reducing installation costs and cable clutter.

Ideal for offices, warehouses, schools, hotels, retail stores, factories, and commercial buildings, the switch delivers dependable performance for continuous surveillance operation.

250-Meter Long Range PoE

The integrated Extend Mode supports PoE and data transmission up to 250 meters, significantly exceeding the standard Ethernet distance when deploying compatible surveillance cameras.

This makes the switch perfect for perimeter security, parking areas, warehouses, campuses, and other installations where cameras are positioned far from the network cabinet.

Reliable 150W Power over Ethernet

Supporting both IEEE 802.3af and IEEE 802.3at standards, the switch provides up to 150 watts of total PoE power, eliminating the need for separate power adapters for connected devices.

This simplifies installation while ensuring reliable operation for IP cameras, wireless access points, and VoIP phones.

Intelligent Surveillance Features

The switch includes dedicated surveillance functions such as VLAN Mode, QoS Priority Mode, and PoE Watchdog, helping improve network security, prioritize video traffic, and automatically recover unresponsive PoE devices.

These intelligent features enhance overall network reliability and maintain uninterrupted CCTV operation.

Durable Fanless Design

The robust metal housing combined with a fanless cooling system ensures quiet operation while efficiently dissipating heat for long-term reliability.

Integrated 6KV surge protection further safeguards connected equipment against electrical spikes and lightning-induced surges.

Ideal Applications

• IP CCTV Surveillance: Perfect for powering and connecting multiple IP cameras.
• Business Networks: Suitable for offices, SMBs, and enterprise networking.
• Educational Institutions: Reliable connectivity for schools, colleges, and universities.
• Retail & Hospitality: Ideal for hotels, shopping malls, restaurants, and retail stores.
• Industrial Facilities: Excellent for warehouses, factories, and logistics centers.
• Wireless Networking: Supports PoE-enabled wireless access point deployments.

Benefits

• Long-Distance Connectivity: Supports PoE transmission up to 250 meters.
• High PoE Capacity: 150W budget powers multiple PoE devices efficiently.
• Gigabit Uplink Performance: Fast uplinks reduce network bottlenecks.
• Enhanced Network Security: VLAN mode isolates traffic for improved protection.
• Reliable Surveillance: QoS and PoE Watchdog improve video stability.
• Silent Operation: Fanless metal chassis ensures quiet performance.
• Easy Installation: Plug-and-Play design requires no configuration.

Why Choose D-Link DES-F1016P-E/B

• 16 PoE+ Ports: Power and connect multiple surveillance devices.
• 250m Long Range Mode: Ideal for extended CCTV deployments.
• 150W PoE Budget: Reliable power delivery for professional installations.
• Gigabit Uplink Ports: High-speed backbone connectivity.
• Surveillance-Optimized Features: VLAN, QoS, and PoE Watchdog functionality.
• Industrial-Grade Reliability: Metal housing with 6KV surge protection.
• Trusted D-Link Quality: Proven networking performance for business and security applications.

Important Considerations

• Long Range Mode: Maximum 250m transmission is available when Extend Mode is enabled and compatible cabling is used.
• PoE Budget: Ensure the combined power consumption of connected devices does not exceed 150W.
• SFP Module: Fiber module is sold separately if SFP connectivity is required.
• Unmanaged Switch: Designed for Plug-and-Play operation without advanced Layer 2 management features.
