Ubiquiti U7 Long-Range Access Point | WiFi 7 | 5 Spatial Streams | 4.3 Gbps | 2.5 GbE | White | U7-LR

Ubiquiti U7 Long-Range Access Point | WiFi 7 | 5 Spatial Streams | 4.3 Gbps | 2.5 GbE | White | U7-LR

The Ubiquiti U7 Long-Range (U7-LR) is a high-performance enterprise wireless access point designed to deliver extended WiFi coverage, high-speed connectivity, and reliable performance for modern business and high-density network environments. Built around the WiFi 7 standard, the U7-LR combines five spatial streams with a 2.5 GbE uplink and up to 4.3 Gbps maximum 5 GHz data rate for demanding wireless applications. Designed for ceiling or wall installation, the U7-LR provides coverage of up to approximately 160 m² (1,750 ft²) and supports 300+ clients. Its 5 GHz 3x3 and 2.4 GHz 2x2 MU-MIMO configuration makes it suitable for offices, commercial spaces, educational environments, hospitality locations, and other deployments requiring strong and scalable wireless connectivity.

Key Features

• WiFi 7 Standard: Supports the latest IEEE 802.11be WiFi 7 technology.
• 5 Spatial Streams: 5-stream wireless architecture for improved network capacity and performance.
• Up to 4.3 Gbps: Maximum 5 GHz data rate with 160 MHz channel bandwidth.
• 2.5 GbE Uplink: High-speed wired network connection for minimizing Ethernet bottlenecks.
• Extended Coverage: Designed to cover up to approximately 160 m² (1,750 ft²).
• 300+ Client Capacity: Suitable for environments with a large number of connected devices.
• 5 GHz 3x3 MU-MIMO: Supports simultaneous communication with multiple compatible clients.
• 2.4 GHz 2x2 MU-MIMO: Provides dependable connectivity for compatible 2.4 GHz devices.
• Wireless Meshing: Supports UniFi wireless mesh deployments.
• Advanced UniFi Features: Includes band steering, fast roaming, RRM, guest isolation, VLAN-related features, and WiFi scheduling.
• PoE Powered: Designed for convenient Power over Ethernet installation.
• Ceiling or Wall Mounting: Suitable for professional fixed wireless deployments.
• White Finish: Compact, professional design for modern commercial interiors.

Technical Specifications

• Brand: Ubiquiti
• Product Series: UniFi
• Model: U7 Long-Range
• Model Number: U7-LR
• Product Type: Enterprise WiFi Access Point
• WiFi Standard: WiFi 7 (802.11be)
• Spatial Streams: 5
• 5 GHz MIMO: 3x3 DL/UL MU-MIMO
• 2.4 GHz MIMO: 2x2 DL/UL MU-MIMO
• Maximum 5 GHz Data Rate: 4.3 Gbps (BW160)
• Maximum 2.4 GHz Data Rate: 688 Mbps (BW40)
• 5 GHz Antenna Gain: 6 dBi
• 2.4 GHz Antenna Gain: 4 dBi
• Maximum Client Count: 300+
• Coverage Area: Up to 160 m² (1,750 ft²)
• Uplink: 1x 2.5 GbE RJ45 port
• Power Method: PoE
• Maximum Power Consumption: 14W
• Mounting: Ceiling or Wall
• Dimensions: Ø175.7 x 43 mm
• Weight: 448 g
• Operating Temperature: -30°C to 50°C
• Operating Humidity: 5% to 95% non-condensing
• Management: UniFi Network
• Colour: White

WiFi 7 Wireless Performance

The U7-LR uses WiFi 7 technology to provide high-speed wireless connectivity with support for modern high-bandwidth applications. Its 5 GHz radio can deliver up to 4.3 Gbps under supported conditions with 160 MHz channel bandwidth, while the 2.4 GHz radio provides up to 688 Mbps. Actual wireless performance depends on client capability, channel conditions, interference, network configuration, and environmental factors.

5 Spatial Streams & MU-MIMO

With a combined 5 spatial streams, the U7-LR is designed to efficiently serve multiple wireless clients. The 5 GHz radio uses 3x3 MU-MIMO, while the 2.4 GHz radio uses 2x2 MU-MIMO, helping compatible devices communicate efficiently in environments with multiple simultaneous users.

Extended Wireless Coverage

The U7-LR is designed for extended-range wireless deployments, offering a manufacturer-rated coverage area of up to approximately 160 m² (1,750 ft²). Coverage can vary significantly depending on building construction, walls, interference, access point placement, client devices, and other environmental conditions.

2.5 GbE High-Speed Uplink

A 2.5 GbE RJ45 uplink provides a high-speed wired connection between the access point and the network infrastructure. This helps support the higher wireless throughput available with WiFi 7 while reducing the limitations associated with a conventional Gigabit Ethernet uplink.

UniFi Network Management

The U7-LR is designed to operate as part of the Ubiquiti UniFi ecosystem, allowing centralized management and configuration through UniFi Network. Supported features include wireless meshing, band steering, fast roaming, radio resource management, guest network isolation, client device isolation, WiFi speed limiting, WiFi schedules, captive portal functionality, and advanced authentication options.

Professional PoE Installation

Power over Ethernet allows the U7-LR to receive power through the network connection, helping simplify installation by reducing the need for a separate local power connection at the access point location. It is suitable for professional ceiling or wall deployments where centralized network and power infrastructure is preferred.

Ideal Applications

• Business Offices: High-performance wireless connectivity for employees, laptops, smartphones, and business devices.
• Commercial Buildings: Extended wireless coverage for offices, shared spaces, and common areas.
• Educational Environments: Suitable for classrooms, training areas, and campuses requiring multiple concurrent connections.
• Hospitality: Wireless infrastructure for hotels, guest areas, lounges, and other customer-facing environments.
• Retail Environments: Connectivity for POS systems, mobile devices, staff equipment, and guest WiFi.
• Enterprise Networks: Suitable for scalable UniFi-based wireless infrastructure.
• High-Client Environments: Designed to support networks with a large number of connected wireless devices.
• Multi-Access-Point Deployments: Ideal for larger installations using multiple UniFi access points.

Benefits

• High-Speed WiFi: Provides WiFi 7 connectivity with up to 4.3 Gbps 5 GHz data rates.
• Extended Coverage: Designed for broader wireless coverage in suitable indoor environments.
• High Client Capacity: Supports 300+ clients according to manufacturer specifications.
• Faster Network Uplink: 2.5 GbE connectivity helps accommodate high wireless throughput.
• Efficient Multi-Client Performance: 5 spatial streams and MU-MIMO support help serve multiple compatible devices.
• Centralized Management: UniFi Network provides centralized configuration and network management.
• Flexible Installation: Ceiling and wall mounting options support different deployment requirements.
• Scalable Infrastructure: Can be integrated into larger UniFi wireless networks.

Why Choose Ubiquiti U7 Long-Range

• WiFi 7 Technology: Built for modern high-performance wireless networking.
• Long-Range Design: Developed to provide extended wireless coverage for suitable indoor environments.
• 5 Spatial Streams: Provides additional wireless capacity for multi-device environments.
• 2.5 GbE Uplink: Supports faster wired connectivity than standard Gigabit Ethernet.
• 300+ Client Support: Designed for demanding deployments with many connected devices.
• UniFi Ecosystem: Works with the broader UniFi networking platform for centralized management and scalability.

Important Considerations

• PoE Requirement: The U7-LR is designed for PoE-powered installation. Ensure the network infrastructure provides compatible PoE power.
• 2.5 GbE Infrastructure: To take full advantage of the 2.5 GbE uplink, compatible networking equipment and cabling are recommended.
• WiFi 7 Client Compatibility: Maximum WiFi 7 performance requires compatible client devices. Older WiFi generations can still connect using their supported standards.
• Real-World Speed: Actual throughput depends on client hardware, channel width, interference, distance, network configuration, and environmental conditions.
• Coverage: The stated coverage area is a manufacturer rating and should not be treated as a guaranteed range for every building.
• UniFi Management: A compatible UniFi Network environment is required for centralized management and configuration.

Why Buy from IT Splendid (UAE)

• Networking Products: IT Splendid provides professional networking equipment including wireless access points, routers, switches, adapters, and network accessories.
• Business Technology: Find enterprise networking, computer products, office equipment, security solutions, and technology accessories for business and professional requirements.
• Professional Solutions: Suitable products are available for office networks, commercial environments, enterprise deployments, and infrastructure upgrades.
• UAE Delivery: Delivery available across Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain, and other Emirates.
• Complete Technology Range: IT Splendid provides computers, gaming products, office equipment, printers, networking products, electronics, appliances, and technology accessories across the UAE.

The Ubiquiti U7 Long-Range U7-LR is a powerful WiFi 7 access point designed for extended wireless coverage, high client capacity, and fast network performance. With 5 spatial streams, up to 4.3 Gbps 5 GHz data rates, 2.5 GbE uplink, PoE installation, and centralized UniFi management, it is an excellent choice for businesses and professional environments looking to build a scalable, high-performance wireless network.
