Eaton 5PX1500IRT2UG2 – 48 V Extended Battery Module (EBM) for 5PX Gen2 UPS

Eaton 5PX1500IRT2UG2 – 48 V Extended Battery Module (EBM) for 5PX Gen2 UPS

The Eaton 5PX1500IRT2UG2 is a reliable uninterruptible power supply (UPS) designed to provide clean, stable power to servers, network gear, workstations, NAS/storage, and other critical electronics. With a compact 2U rack/tower design, pure-sine output and automatic voltage regulation, it ensures continuous operation and protection against voltage fluctuations, outages or brownouts — ideal for offices, data closets, small data-centers or home labs.

Key Features

• 1500 VA / 1500 W Capacity with Unity Power Factor: Delivers full wattage (not just VA), giving you more usable power for connected equipment.
• Line-Interactive Topology with Pure Sine-Wave Output: Ensures clean, stable power — safe for sensitive and PFC power-supply devices.
• Rack or Tower Installation (2U) with Mounting Kit Included: Flexible for server racks or standalone setups.
• 8 × IEC C13 Output Outlets: Enough sockets to support multiple devices — servers, switches, NAS, modems, etc.
• Automatic Voltage Regulation (AVR): Stabilizes input voltage (boosts or bucks) within 160–294 V range — protects against fluctuations common in unstable power grids.
• Replaceable Lead-acid Batteries + Expandable Runtime: 4 internal batteries (12 V / 9 Ah), with option to connect external battery modules for extended runtime.
• Intelligent Monitoring & Management Ready: Graphical LCD display for real-time status, plus USB + serial interface, remote ON/OFF, relay / dry-contact outputs, and slot for optional network/management card.
• Energy Efficient & Quiet Operation: Up to ≈ 98% efficiency at full load, low noise < 40 dB — good for office or home-office environments.

Technical Specifications

• Model / Part Number: 5PX1500IRT2UG2
• VA / Watt Rating: 1500 VA / 1500 W
• Topology: Line-Interactive with pure sine-wave output
• Input Voltage Range: 160–294 V (user-adjustable to 150–294 V)
• Input Frequency Range: 50–60 Hz; 47–70 Hz (50 Hz system) or 56.5–70 Hz (60 Hz system); 40 Hz in low-sensitivity mode
• Output Voltage: 230 V nominal (selectable: 200/208/220/230/240 V)
• Output Outlets: 8 × IEC C13
• Form Factor: Rack/tower convertible, 2U (19″ rack compatible) with included rack-mount kit
• Dimensions (W × D × H): 438 × 448 × 85.5 mm
• Weight: ~ 22.4 kg
• Batteries: 4 × 12 V / 9 Ah sealed lead-acid, user-replaceable; hot-swappable; supports external battery modules (EBMs) for runtime extension
• User Interface & Connectivity: Graphical LCD display, USB (HID), RS-232 serial, remote On/Off, relay / dry-contact outputs, expansion slot for optional management card.
• Operating Conditions: 0–40 °C ambient temperature; altitude up to 3000 m; noise < 40 dB at 1 m

Ideal For

• Small to medium businesses, server rooms, or home-office setups requiring clean, uninterrupted power.
• Servers, NAS devices, workstations, networking gear, storage arrays, and PFC-enabled power supplies.
• Virtualization hosts, data closets, or small data-center's needing UPS with rack or tower flexibility.
• Environments with unstable or fluctuating power — the AVR helps maintain stable output and protects sensitive devices.
• Use cases needing expandable runtime — option to attach external battery modules for longer battery backup.

Why Buy from IT Splendid (UAE)

• Genuine Eaton 5PX Gen2 Unit — Model 5PX1500IRT2UG2, not a budget or “grey-market” substitute.
• Versatile Rack or Tower Installation — includes mounting kit, suitable for server racks or standalone installation.
• Clean Sine-Wave Output & UPS Protection for Important Gear — ideal for business-critical servers, storage, networking and home labs.
• Expandable & Manageable — battery replacement, external battery expansion, monitoring, and remote management support make it suitable for evolving infrastructure.
• Efficient & Energy-Saving — high efficiency (~98%) helps reduce power waste and cooling costs, helpful for continuous operation in offices or data-center's.

Choose the Eaton 5PX1500IRT2UG2 UPS when you need dependable, scalable, and efficient power protection for servers, network equipment, NAS/storage or mission-critical electronics — a great balance of power, functionality and flexibility for UAE offices, labs or small data-centres.
