Eaton 9SX5KIRT – 5000 VA / 4500 W Online Rack‑/Tower UPS (3U)

Eaton 9SX5KIRT – 5000 VA / 4500 W Online Rack‑/Tower UPS (3U)

The Eaton 9SX5KIRT UPS is a high‑performance, online (double‑conversion) uninterruptible power supply designed to deliver clean, stable and regulated power for servers, data‑center racks, networking infrastructure, storage arrays, and other critical equipment. With a 5000 VA / 4500 W capacity, charger‑friendly hot‑swappable batteries, and flexible rack/tower mounting, it’s ideal for data centres, server rooms, network closets, and business‑class IT setups.

Key Features

• True Online Double‑Conversion Topology: Provides pure sine‑wave output and full isolation from mains fluctuations — surges, sags, brownouts or frequency variations.
• 5000 VA / 4500 W Output (0.9 PF): Powerful enough to support multiple servers, storage arrays, network switches, and mixed IT loads.
• Rack or Tower (3U) Convertible Design: 19″ rack‑mountable (3U) — but also deployable as a standalone tower — with included rack‑mount kit.
• Multiple Output Outlets: (8) IEC C13 + (2) IEC C19 + hardwired output — supports servers, storage, networking gear, and peripherals.
• Hot‑Swappable Internal Batteries + EBM Support: 15 sealed lead‑acid batteries (12 V/5 Ah) with ABM battery management, automatic battery tests, and support for external battery modules (EBMs) for extended runtime.
• Wide Input Range & High Input PF: Accepts 176–276 V (and 100–276 V with derating) and 40–70 Hz, with input power factor > 0.99 — good for unstable power environments.
• Graphical LCD & Monitoring Interfaces: Multilingual LCD display plus USB (HID), RS‑232, dry contacts, remote On/Off — supports remote monitoring via software.
• High Efficiency: Up to ~94% efficiency in online mode, helping reduce heat and power losses.
• Internal Bypass & Auto-Shutdown: Built‑in bypass allows maintenance or UPS fault handling without interruption; auto shutdown ensures safe power‑off for connected equipment if necessary.

Technical Specifications

• Model / Part Number: 9SX5KIRT
• Topology: Online / Double‑conversion
• Output Capacity: 5000 VA / 4500 W (0.9 power factor)
• Output Voltage: 230 V nominal (configurable 200 / 208 / 220 / 230 / 240 V)
• Output Waveform: Pure sine wave
• Output Outlets: 8 × IEC C13, 2 × IEC C19, plus one hardwired output
• Input Voltage Range: 176–276 V (100–276 V with derating)
• Input Frequency Range: 40–70 Hz (auto 50/60 Hz)
• Battery Type: Sealed lead‑acid, 15 × 12 V / 5 Ah
• Batteries Hot‑Swappable: Yes
• Extended Battery Support: External Battery Modules (EBMs) supported
• Form Factor / Rack Size: 3U, 19″ rack‑mountable / Tower convertible
• Dimensions (WxDxH): 440 × 685 × 130 mm (approx.)
• Weight: ~48 kg
• Noise Level: < 45 dB at 1 metre
• Communications / Interface: USB (HID), RS‑232 serial, dry contacts, remote On/Off/Off switch, one expansion slot for optional network/communication card; LCD display for status.
• Certifications / Compliance: CE, IEC/EN 62040‑1 / 62040‑2, UL 1778, cULus, CSA 22.2, EAC

Ideal For

• Server rooms, data‑centre racks, and networking closets — powering multiple servers, storage, switches, and core infrastructure requiring clean, uninterrupted power.
• Small to medium businesses running mixed loads (servers + NAS + networking + peripherals) where a 5 kVA UPS is required.
• Offices or work environments needing reliable backup power for critical equipment during outages or voltage instability.
• Setups requiring rack‑mount or tower flexibility — fits both traditional racks and standalone server cabinets or closets.
• Environments where battery runtime needs may grow — support for external battery modules (EBMs) provides scalability for longer UPS runtime.

Why Buy from IT Splendid (UAE)

• 100% Genuine Eaton Product: Official 9SX5KIRT model — not a grey‑market or refurbished item.
• Ready for UAE Power Environment: Compatible with standard 220‑240 V, 50 Hz mains — ideal for offices, data centres or labs in UAE.
• Rack & Tower Flexibility: Rack‑mountable 3U form factor with included kit, but also deployable as standalone tower — easy to integrate in varied infrastructure layouts.
• Scalable & Future‑Ready: Hot‑swappable batteries with external battery support — you can expand runtime as infrastructure or power demand increases.
• Enterprise‑Grade Protection & Performance: Online double‑conversion, pure sine‑wave output, wide input tolerance, and efficient design — ideal for mission‑critical servers, storage, and networking equipment.

Choose the Eaton 9SX5KIRT UPS for robust, enterprise‑grade power protection — a reliable foundation for data centres, server racks, network infrastructure, or any critical electronics setup in UAE offices or data environments.
